在金融数据分析领域，策略回测是每位量化投资者的必修课。今天分享的这套三策略信号K线图系统，经过实测可处理688360、603300等股票数据，生成可视化回测报告。本文将通过真实案例，手把手教你从基础配置到高级应用。
一、系统架构解析：三把利器的协同作战
这套系统整合了移动平均线、RSI相对强弱指标、布林带三大经典策略，每个策略都有明确的交易逻辑：
移动平均线策略采用5日与20日均线组合，当短期均线上穿长期均线时触发买入信号，反之则卖出。这种策略在趋势行情中表现突出，尤其适合中长期持有。
def generate_signals(self, df):
"""生成MA信号"""
df = df.copy()
df['short_ma'] = df['close'].rolling(window=self.params['short_ma']).mean()
df['long_ma'] = df['close'].rolling(window=self.params['long_ma']).mean()
# 生成交易信号
df['signal'] = 0
# 金叉买入，死叉卖出
df.loc[df['short_ma'] > df['long_ma'], 'signal'] = 1
df.loc[df['short_ma'] < df['long_ma'], 'signal'] = -1
# 生成持仓状态
df['position'] = df['signal'].diff()
return dfRSI策略设置30超卖、70超买阈值，通过14日周期计算相对强弱。当RSI从超卖区回升时建仓，从超买区回落时平仓，有效捕捉震荡行情中的反转机会。
def generate_signals(self, df):
"""生成RSI信号"""
df = df.copy()
df['rsi'] = self.calculate_rsi(df, self.params['rsi_period'])
df['signal'] = 0
df['position'] = 0
# 使用状态机方式生成信号
in_position = False
for i in range(1, len(df)):
rsi = df['rsi'].iloc[i]
prev_rsi = df['rsi'].iloc[i-1]
if not in_position and rsi < self.params['oversold'] and prev_rsi >= self.params['oversold']:
df.loc[df.index[i], 'signal'] = 1
in_position = True
elif in_position and rsi > self.params['overbought'] and prev_rsi <= self.params['overbought']:
df.loc[df.index[i], 'signal'] = -1
in_position = False
return df布林带策略基于20日均线构建上下轨，价格突破下轨后反弹买入，触及上轨后回落卖出。这种策略对波动率变化敏感，适合波段操作。
def generate_signals(self, df):
"""生成布林带信号"""
df = self.calculate_bollinger_bands(df)
df['signal'] = 0
# 使用状态机方式生成信号
in_position = False
for i in range(1, len(df)):
close = df['close'].iloc[i]
prev_close = df['close'].iloc[i-1]
bb_lower = df['bb_lower'].iloc[i]
bb_upper = df['bb_upper'].iloc[i]
prev_bb_lower = df['bb_lower'].iloc[i-1]
prev_bb_upper = df['bb_upper'].iloc[i-1]
# 价格从下向上突破下轨买入
if not in_position and prev_close <= prev_bb_lower and close > bb_lower:
df.loc[df.index[i], 'signal'] = 1
in_position = True
# 价格从上向下突破上轨卖出
elif in_position and prev_close >= prev_bb_upper and close < bb_upper:
df.loc[df.index[i], 'signal'] = -1
in_position = False
return df二、环境搭建：30分钟完成配置
系统依赖三个核心库：akshare负责获取实时股票数据，pandas处理数据清洗，pyecharts生成交互式图表。安装命令如下：
pip install akshare pandas pyecharts首次运行时，系统会自动下载688360（德马科技）等示例数据，测试环境是否正常。提议先运行单只股票验证，再扩展到多股票分析。
三、实战案例：603300海南华铁完整分析
以海南华铁为例，演示完整分析流程。设置2020-2025年回测周期，初始资金10万元，系统会输出三策略对比结果：
analyzer = MultiStrategyAnalyzer()
results = analyzer.run_all_strategies("603300", "2020-01-01", "2025-12-31")运行后生成四个关键文件：603300_ma_策略信号图.html展示移动平均线买卖点，603300_rsi_策略信号图.html标注RSI反转位置，603300_bollinger_策略信号图.html显示布林带突破时机，以及策略对比报告。
四、深度应用：参数优化与风险控制
系统支持自定义参数，例如将RSI周期调整为21日，超买超卖阈值设为25/75，可适应不同市场环境。
通过修改策略类的__init__方法实现
# 自定义RSI参数
rsi_strategy = RSIStrategy(rsi_period=21, oversold=25, overbought=75)风险控制方面，提议设置单笔交易不超过总资金的20%，连续亏损3次暂停交易。可在backtest方法中添加止损逻辑，当单日跌幅超过5%时强制平仓。
五、数据验证：真实回测结果对比
以688360德马科技为例，2020-2025年回测显示：MA策略产生72次交易，最终收益率6.41%；RSI策略交易30次，收益率139.97%；布林带策略交易24次，收益率50.53%。数据证明趋势策略在成长股中优势明显。
================================================================================
688360 - 三策略回测结果对比
================================================================================
策略名称 最终资金 收益率 交易次数
--------------------------------------------------------------------------------
MA策略 106408.81 6.41% 72
RSI策略 239972.33 139.97% 30
布林带策略 150525.21 50.53% 24
最佳策略: rsi
最终收益: 239972.33元
收益率: 139.97%
✅ 德马科技 分析完成！系统生成的HTML图表支持鼠标悬停查看详情，绿色三角形标记买入点，红色三角形标记卖出点，成交量柱状图辅助判断信号有效性。
六、常见问题解决方案
数据获取失败：检查股票代码是否正确，部分科创板股票需使用完整代码。网络异常时可先用本地CSV文件测试。
信号过于频繁：调整参数阈值，如将MA策略的均线周期改为10/30组合，减少交易次数。
图表显示异常：确认pyecharts版本≥1.9，旧版本可能出现坐标轴错位。
七、进阶技巧：多股票批量分析
通过循环调用可实现批量分析，提议分批处理避免接口限制：
stock_list = ["601918", "603300", "688360"]
for code in stock_list:
analyzer.run_all_strategies(code, "2023-01-01", "2024-12-31")系统会自动为每只股票生成独立报告，便于横向对比不同策略在各股票上的表现差异。
八、使用提议与风险提示
本系统适用于技术分析学习者、量化入门者，提议先用模拟盘验证3个月以上再实盘应用。历史回测不代表未来收益，实际交易需思考滑点、手续费等因素。
免责声明：本文提供的工具仅用于教育目的，不构成投资提议。股市有风险，投资需谨慎。使用者应充分了解相关风险，自主决策并承担相应后果。
这套系统已协助多位用户完成策略验证，你准备从哪个股票开始测试？欢迎在实践中分享使用心得。
完整代码（有兴趣的可以关注我，共同研究）
# 修正三策略信号K线图系统.py
import pandas as pd
import akshare as ak
from pyecharts.charts import Kline, Line, Scatter
from pyecharts import options as opts
import warnings
import os
warnings.filterwarnings('ignore')
class StockDataLoader:
"""股票数据获取器"""
def __init__(self):
pass
def get_stock_data(self, stock_code, start_date, end_date):
"""获取股票历史数据"""
try:
df = ak.stock_zh_a_hist(
symbol=stock_code,
period="daily",
start_date=start_date.replace('-', ''),
end_date=end_date.replace('-', ''),
adjust="qfq"
)
if df.empty:
raise ValueError("获取数据为空")
# 重命名列
df = df.rename(columns={
'日期': 'date',
'开盘': 'open',
'收盘': 'close',
'最高': 'high',
'最低': 'low',
'成交量': 'volume'
})
df['date'] = pd.to_datetime(df['date'])
df = df.sort_values('date')
df.set_index('date', inplace=True)
return df
except Exception as e:
print(f"获取股票数据失败: {e}")
return None
class BaseStrategy:
"""基础策略类"""
def __init__(self, name, params):
self.name = name
self.params = params
def generate_signals(self, df):
"""生成交易信号"""
pass
def backtest(self, df, initial_capital=100000):
"""回测策略"""
pass
class MaStrategy(BaseStrategy):
"""移动平均线策略"""
def __init__(self, short_ma=5, long_ma=20):
super().__init__('MA策略', {'short_ma': short_ma, 'long_ma': long_ma})
def generate_signals(self, df):
"""生成MA信号"""
df = df.copy()
df['short_ma'] = df['close'].rolling(window=self.params['short_ma']).mean()
df['long_ma'] = df['close'].rolling(window=self.params['long_ma']).mean()
# 生成交易信号
df['signal'] = 0
# 金叉买入，死叉卖出
df.loc[df['short_ma'] > df['long_ma'], 'signal'] = 1
df.loc[df['short_ma'] < df['long_ma'], 'signal'] = -1
# 生成持仓状态
df['position'] = df['signal'].diff()
return df
def backtest(self, df, initial_capital=100000):
"""回测MA策略"""
df = self.generate_signals(df)
capital = initial_capital
position = 0
trades = []
for i in range(1, len(df)):
date = df.index[i]
row = df.iloc[i]
prev_row = df.iloc[i-1]
# 金叉买入
if prev_row['short_ma'] <= prev_row['long_ma'] and row['short_ma'] > row['long_ma']:
if position == 0:
shares = int(capital / row['close'])
if shares > 0:
cost = shares * row['close']
capital -= cost
position = shares
trades.append({
'date': date,
'type': 'buy',
'price': row['close'],
'shares': shares,
'value': cost,
'capital': capital
})
# 死叉卖出
elif prev_row['short_ma'] >= prev_row['long_ma'] and row['short_ma'] < row['long_ma']:
if position > 0:
value = position * row['close']
capital += value
trades.append({
'date': date,
'type': 'sell',
'price': row['close'],
'shares': position,
'value': value,
'capital': capital
})
position = 0
final_value = capital + position * df['close'].iloc[-1]
return {
'final_value': final_value,
'return_rate': (final_value - initial_capital) / initial_capital,
'trades': trades,
'df': df
}
class RSIStrategy(BaseStrategy):
"""RSI相对强弱指标策略"""
def __init__(self, rsi_period=14, oversold=30, overbought=70):
super().__init__('RSI策略', {
'rsi_period': rsi_period,
'oversold': oversold,
'overbought': overbought
})
def calculate_rsi(self, df, period=14):
"""计算RSI指标"""
delta = df['close'].diff()
gain = (delta.where(delta > 0, 0)).rolling(window=period).mean()
loss = (-delta.where(delta < 0, 0)).rolling(window=period).mean()
rs = gain / loss
rsi = 100 - (100 / (1 + rs))
return rsi
def generate_signals(self, df):
"""生成RSI信号"""
df = df.copy()
df['rsi'] = self.calculate_rsi(df, self.params['rsi_period'])
df['signal'] = 0
df['position'] = 0
# 使用状态机方式生成信号
in_position = False
for i in range(1, len(df)):
rsi = df['rsi'].iloc[i]
prev_rsi = df['rsi'].iloc[i-1]
if not in_position and rsi < self.params['oversold'] and prev_rsi >= self.params['oversold']:
df.loc[df.index[i], 'signal'] = 1
in_position = True
elif in_position and rsi > self.params['overbought'] and prev_rsi <= self.params['overbought']:
df.loc[df.index[i], 'signal'] = -1
in_position = False
return df
def backtest(self, df, initial_capital=100000):
"""回测RSI策略"""
df = self.generate_signals(df)
capital = initial_capital
position = 0
trades = []
for i in range(1, len(df)):
date = df.index[i]
row = df.iloc[i]
prev_row = df.iloc[i-1]
# RSI从超卖区域回升买入
if prev_row['signal'] != 1 and row['signal'] == 1:
if position == 0:
shares = int(capital / row['close'])
if shares > 0:
cost = shares * row['close']
capital -= cost
position = shares
trades.append({
'date': date,
'type': 'buy',
'price': row['close'],
'shares': shares,
'value': cost,
'capital': capital,
'rsi': row.get('rsi', 0)
})
# RSI从超买区域回落卖出
elif prev_row['signal'] != -1 and row['signal'] == -1:
if position > 0:
value = position * row['close']
capital += value
trades.append({
'date': date,
'type': 'sell',
'price': row['close'],
'shares': position,
'value': value,
'capital': capital,
'rsi': row.get('rsi', 0)
})
position = 0
final_value = capital + position * df['close'].iloc[-1]
return {
'final_value': final_value,
'return_rate': (final_value - initial_capital) / initial_capital,
'trades': trades,
'df': df
}
class BollingerStrategy(BaseStrategy):
"""布林带策略"""
def __init__(self, bb_period=20, bb_std=2):
super().__init__('布林带策略', {
'bb_period': bb_period,
'bb_std': bb_std
})
def calculate_bollinger_bands(self, df):
"""计算布林带"""
df = df.copy()
df['bb_middle'] = df['close'].rolling(window=self.params['bb_period']).mean()
df['bb_std'] = df['close'].rolling(window=self.params['bb_period']).std()
df['bb_upper'] = df['bb_middle'] + (df['bb_std'] * self.params['bb_std'])
df['bb_lower'] = df['bb_middle'] - (df['bb_std'] * self.params['bb_std'])
return df
def generate_signals(self, df):
"""生成布林带信号"""
df = self.calculate_bollinger_bands(df)
df['signal'] = 0
# 使用状态机方式生成信号
in_position = False
for i in range(1, len(df)):
close = df['close'].iloc[i]
prev_close = df['close'].iloc[i-1]
bb_lower = df['bb_lower'].iloc[i]
bb_upper = df['bb_upper'].iloc[i]
prev_bb_lower = df['bb_lower'].iloc[i-1]
prev_bb_upper = df['bb_upper'].iloc[i-1]
# 价格从下向上突破下轨买入
if not in_position and prev_close <= prev_bb_lower and close > bb_lower:
df.loc[df.index[i], 'signal'] = 1
in_position = True
# 价格从上向下突破上轨卖出
elif in_position and prev_close >= prev_bb_upper and close < bb_upper:
df.loc[df.index[i], 'signal'] = -1
in_position = False
return df
def backtest(self, df, initial_capital=100000):
"""回测布林带策略"""
df = self.generate_signals(df)
capital = initial_capital
position = 0
trades = []
for i in range(1, len(df)):
date = df.index[i]
row = df.iloc[i]
prev_row = df.iloc[i-1]
# 布林带突破买入信号
if prev_row['signal'] != 1 and row['signal'] == 1:
if position == 0:
shares = int(capital / row['close'])
if shares > 0:
cost = shares * row['close']
capital -= cost
position = shares
trades.append({
'date': date,
'type': 'buy',
'price': row['close'],
'shares': shares,
'value': cost,
'capital': capital
})
# 布林带突破卖出信号
elif prev_row['signal'] != -1 and row['signal'] == -1:
if position > 0:
value = position * row['close']
capital += value
trades.append({
'date': date,
'type': 'sell',
'price': row['close'],
'shares': position,
'value': value,
'capital': capital
})
position = 0
final_value = capital + position * df['close'].iloc[-1]
return {
'final_value': final_value,
'return_rate': (final_value - initial_capital) / initial_capital,
'trades': trades,
'df': df
}
class MultiStrategyAnalyzer:
"""多策略分析器"""
def __init__(self):
self.data_loader = StockDataLoader()
self.strategies = {
'ma': MaStrategy(),
'rsi': RSIStrategy(),
'bollinger': BollingerStrategy()
}
def run_all_strategies(self, stock_code, start_date, end_date):
"""运行所有策略"""
print(f"正在获取{stock_code}的历史数据...")
df = self.data_loader.get_stock_data(stock_code, start_date, end_date)
if df is None:
return None
results = {}
for strategy_name, strategy in self.strategies.items():
print(f"
正在运行{strategy.name}策略...")
result = strategy.backtest(df)
results[strategy_name] = result
# 生成策略信号图
self.create_strategy_chart(df, result['trades'], stock_code, strategy.name, strategy_name)
# 输出对比结果
self.print_comparison_results(stock_code, results)
return results
def create_strategy_chart(self, df, trades, stock_code, strategy_name, strategy_key):
"""创建策略信号图"""
kline_data = df[['open', 'close', 'low', 'high']].values.tolist()
dates = df.index.strftime('%Y-%m-%d').tolist()
# 创建K线图
kline = (
Kline()
.add_xaxis(dates)
.add_yaxis(
series_name="K线",
y_axis=kline_data,
itemstyle_opts=opts.ItemStyleOpts(
color="#ef232a",
color0="#14b143"
)
)
.set_global_opts(
title_opts=opts.TitleOpts(
title=f"{stock_code} - {strategy_name}信号图",
subtitle=f"回测期间: {dates[0]} 至 {dates[-1]}"
),
xaxis_opts=opts.AxisOpts(type_="category"),
yaxis_opts=opts.AxisOpts(is_scale=True),
tooltip_opts=opts.TooltipOpts(trigger="axis"),
datazoom_opts=[opts.DataZoomOpts(), opts.DataZoomOpts(type_="slider")]
)
)
# 添加技术指标
if strategy_key == 'ma':
df['ma5'] = df['close'].rolling(5).mean()
df['ma20'] = df['close'].rolling(20).mean()
line = Line().add_xaxis(dates)
line.add_yaxis("MA5", df['ma5'].round(2).tolist(), is_smooth=True)
line.add_yaxis("MA20", df['ma20'].round(2).tolist(), is_smooth=True)
kline = kline.overlap(line)
elif strategy_key == 'rsi':
df['rsi'] = self.strategies['rsi'].calculate_rsi(df)
line = Line().add_xaxis(dates)
line.add_yaxis("RSI", df['rsi'].round(2).tolist(), is_smooth=True)
kline = kline.overlap(line)
elif strategy_key == 'bollinger':
df = self.strategies['bollinger'].calculate_bollinger_bands(df)
line = Line().add_xaxis(dates)
line.add_yaxis("BB Upper", df['bb_upper'].round(2).tolist(), is_smooth=True)
line.add_yaxis("BB Middle", df['bb_middle'].round(2).tolist(), is_smooth=True)
line.add_yaxis("BB Lower", df['bb_lower'].round(2).tolist(), is_smooth=True)
kline = kline.overlap(line)
# 添加买卖标记
buy_dates = [t['date'].strftime('%Y-%m-%d') for t in trades if t['type'] == 'buy']
buy_prices = [t['price'] for t in trades if t['type'] == 'buy']
sell_dates = [t['date'].strftime('%Y-%m-%d') for t in trades if t['type'] == 'sell']
sell_prices = [t['price'] for t in trades if t['type'] == 'sell']
if buy_dates:
buy_scatter = (
Scatter()
.add_xaxis(buy_dates)
.add_yaxis("买入", buy_prices, symbol_size=10, symbol="triangle",
itemstyle_opts=opts.ItemStyleOpts(color="#00FF00"))
)
kline = kline.overlap(buy_scatter)
if sell_dates:
sell_scatter = (
Scatter()
.add_xaxis(sell_dates)
.add_yaxis("卖出", sell_prices, symbol_size=10, symbol="triangle",
itemstyle_opts=opts.ItemStyleOpts(color="#FF0000"),
symbol_rotate=180)
)
kline = kline.overlap(sell_scatter)
# 保存图表
filename = f"{stock_code}_{strategy_key}_策略信号图.html"
kline.render(filename)
print(f"✅ {strategy_name}信号图已保存: {filename}")
def print_comparison_results(self, stock_code, results):
"""打印策略对比结果"""
print("
" + "=" * 80)
print(f"{stock_code} - 三策略回测结果对比")
print("=" * 80)
print(f"{'策略名称':<15}{'最终资金':<12}{'收益率':<12}{'交易次数':<10}")
print("-" * 80)
for strategy_name, result in results.items():
strategy_map = {
'ma': 'MA策略',
'rsi': 'RSI策略',
'bollinger': '布林带策略'
}
final_value = result['final_value']
return_rate = result['return_rate']
trades = result['trades']
print(f"{strategy_map[strategy_name]:<15}{final_value:<12.2f}{return_rate:<12.2%}{len(trades):<10}")
# 找出最佳策略
best_strategy = max(results.items(), key=lambda x: x[1]['final_value'])
print(f"
最佳策略: {best_strategy[0]}")
print(f" 最终收益: {best_strategy[1]['final_value']:.2f}元")
print(f" 收益率: {best_strategy[1]['return_rate']:.2%}")
# 一键运行脚本
if __name__ == "__main__":
analyzer = MultiStrategyAnalyzer()
# 示例股票
stocks = [
{"code": "688360", "name": "德马科技"},
{"code": "603300", "name": "海南华铁"},
{"code": "601918", "name": "新集能源"}
]
start_date = "2020-01-01"
end_date = "2025-12-31"
print(" 开始三策略回测分析...")
for stock in stocks:
print(f"
分析 {stock['name']}({stock['code']})...")
results = analyzer.run_all_strategies(
stock['code'],
start_date,
end_date
)
if results:
print(f"✅ {stock['name']} 分析完成！")
print("
" + "=" * 80)
print(" 所有分析完成！")
print(" 生成的文件:")
for file in os.listdir('.'):
if file.endswith('_策略信号图.html'):
print(f" - {file}")
print("
使用说明:")
print(" 1. 双击HTML文件在浏览器中打开")
print(" 2. 绿色三角形：买入信号")
print(" 3. 红色三角形：卖出信号")
print(" 4. 鼠标悬停查看详细信息")© 版权声明
文章版权归作者所有，未经允许请勿转载。
相关文章
您必须登录才能参与评论！
立即登录
收藏学习转发
感谢收藏转发。
收藏了，感谢分享
感谢转发。
感谢转发
